    TM BF 32 Milling Machine Large Table V2 with SINO 3 axis digital readout system

    Brand: TM
    €2.999,99
    €2.699,99 Out of stock
    • Scherpste prijzen
    • 300,000+ tevreden klanten
    • Fysieke winkel
    • Groot voorraad

    Product description

    Technical data of the TM BF 32 Milling Machine Large Table V2 with SINO 3 axis digital readout system

    Maximum drilling capacity in steel32 mm.
    Maximum milling capacity in steel36 mm.
    Maximum casing milling capacity76 mm.
    Voltage230 volts
    Engine power1500 Watt
    Speed rangeInfinitely adjustable from 50 - 3000 rpm.
    Spindle stroke70 mm.
    RecordingMT3.
    Dimensions Table840 x 210 mm.
    Transverse displacement220 mm.
    Longitudinal displacement565 mm.
    Diameter of the T-Slots14 mm.
    T - Nut sizeM12
    Distance spindle / column200 mm.
    Maximum distance spindle / Table470 mm.
    Placement dimensions76 x 76 x 115 cm.
    Packaging dimensions105.5 x 73 x 114 cm.
    Weight245 Kg.





    This metal milling machine V2 comes standard with.

    • SINO 3-axis digital readout system. (DRO)
    • Drill chuck with pin.
    • Digital depth display.
    • Digital speed reading.
    • Fine adjustment.
    • Variable speed.
    • Left / Right switching.
    • Dovetail protection.
    • Head can be swiveled 90 degrees left / right.
    • Associated tools.

    Specifications

    Article number
    11450
    SKU
    WMD32V-DRO
    EAN
    7433648735769
